Drapers Head for Combine
New Holland equipment
MAXIMUM HARVESTING PRODUCTIVITY
Maximize the capacity of your New Holland combine with a matching New Holland draper head designed for uniform crop flow and reliable performance. Choose from models to match your crop, and available in a range of cutting widths to match your needs.
Overview
Models
Overview
A six-bat New Holland-designed cam reel smoothly feeds crop to the cutterbar and draper belts. The 30- and 35-foot heads feature a single-span, plastic-tine pickup reel while 40- and 45-foot models use a dual-span reel. The 840CD cutterbar handles high-yielding crops cleanly using three-inch guards and over-serrated knife sections with 10 or 14 teeth per inch working at 1260 cuts per minute. The header height control system features four sensors. All header widths (except the 30’ model) come with standard gauge wheels to ensure even stubble height. The hydraulically driven SynchroKnife™ drive system uses a patented single gearbox mounted in the middle of the cutterbar to drive both knife assemblies. This unique and patented design distributes weight evenly, neutralizes header vibration and leads to an exceptionally smooth cutting action. Variable-speed outer draper belts and fixed-speed, twin, 41.6-inch center draper belts deliver the crop smoothly to the floating 26-inch-diameter auger. The auger features five-inch flighting and handles heavy crop, feeding it smoothly into the combine. A flatter auger floor angle aids crop flow. The auger can be adjusted up and down.EVEN FEEDING
CLOSE CUTTING
SMOOTH DRAPER FEEDING
Models
840CD Rigid Draper
| DRAPER FEEDING BELTS WIDTH (IN) | 41.5 |
| REEL DIAMETER – 6 BAT CAM (IN) | 42 |
880CF SuperFlex Draper
| DRAPER FEEDING BELTS WIDTH (IN) | 41.5 |
| CUTTING WIDTH (FT) | 30, 35, 40, 45 |
Overview
Models
Data sheets
Overview
A six-bat New Holland-designed cam reel smoothly feeds crop to the cutterbar and draper belts. The 30- and 35-foot heads feature a single-span, plastic-tine pickup reel while 40- and 45-foot models use a dual-span reel. The 840CD cutterbar handles high-yielding crops cleanly using three-inch guards and over-serrated knife sections with 10 or 14 teeth per inch working at 1260 cuts per minute. The header height control system features four sensors. All header widths (except the 30’ model) come with standard gauge wheels to ensure even stubble height. The hydraulically driven SynchroKnife™ drive system uses a patented single gearbox mounted in the middle of the cutterbar to drive both knife assemblies. This unique and patented design distributes weight evenly, neutralizes header vibration and leads to an exceptionally smooth cutting action. Variable-speed outer draper belts and fixed-speed, twin, 41.6-inch center draper belts deliver the crop smoothly to the floating 26-inch-diameter auger. The auger features five-inch flighting and handles heavy crop, feeding it smoothly into the combine. A flatter auger floor angle aids crop flow. The auger can be adjusted up and down.EVEN FEEDING
CLOSE CUTTING
SMOOTH DRAPER FEEDING
Models
840CD Rigid Draper
| DRAPER FEEDING BELTS WIDTH (IN) | 41.5 |
| REEL DIAMETER – 6 BAT CAM (IN) | 42 |
880CF SuperFlex Draper
| DRAPER FEEDING BELTS WIDTH (IN) | 41.5 |
| CUTTING WIDTH (FT) | 30, 35, 40, 45 |
Data sheets
Combine Headers – Brochure
